Color Coated Aluminum Plate/Coil
Color-coated aluminum coils have a rich range of colors. Whether they are residential buildings, large commercial outlets or large convention and exhibition centers, color-coated aluminum coils can add color to them.
Email: export@xienuoenterprise.com
Color Coated Aluminum Plate/Coil
What Is Color Coated Aluminum Plate/Coil?
Color-coated aluminum coils, as the name suggests, are painted on the surface of aluminum substrates. Commonly used ones include fluorocarbon color-coated aluminum coils, polyester color-coated aluminum coils, etc.
Color Specifications Of Color-Coated Aluminum Sheets/Coils
Color | Color | Raw Material Width | .019 | .024 | .030 | .040 | .050 | .060 |
Dark Grey Metallic | MDG | MDG | 49 | X | ||||
Bronze Metallic | MB | MB | 49 | X | ||||
Light Pewter | MLP | MLP | 49 | X | X | X | ||
Champagne Beige | CBG | CBG | 49 | X | X | |||
Royal Blue (Indigo) | RV | RV | 49 | X | ||||
Windstar Silver Frost | WS | WS | 49 | X | X | |||
Med. Charcoal Grey | CH | CH | 49 | X | X | X | ||
Brandywine | BDY | BDY | 49 | X | X | |||
Crystal White | CW | CW | 49 | X | X | X | X | |
Victory Red | VR | VR | 49 | X | X | |||
Matte Black | BKM | BKM | 49 | X | ||||
Yellow (Penske) | PY | PY | 49 | X | ||||
Cargo Green | CG | CG | 49 | X | ||||
Dove Grey | DG | DG | 49 | X | ||||
Orange | SO | SO | 49 | X | ||||
Clovermist | CV | CV | 48 | X | ||||
Designer Beige | DB | DB | 48 | X | ||||
Black | B | B | 49 | X | X | X | X | |
Colonial White | CO | CO | 48 | X | ||||
Light Grey | GRL | GRL | 48 | X | ||||
Pearl Cat/Arctic Grn | PCG | PCG | 49 | X | ||||
Polar White | P | P | 48 | X | X | |||
Polar White | P | P | 49 | X | X | X | ||
Polar White | P | P | 16, 36 | X | ||||
Deep Blue | DB | DB | 49 | X |
Product Videos
Color Coated Aluminum Plate/Coil Specifications:
Alloy: | 1050 1060 1100 3003 3004 3105 5052 5083 5754 6061 |
Thickness: | 0.08-4.0mm |
Width: | 30mm-1500mm |
Coils core diameter: | 150mm ,405mm, 505mm, 508mm, 510mm |
Coating thickness: | PVDF >=25micron POLYESTER>=18micron |
Color standard: | E < 2 or it is not obvious by eyeballing |
Pencil hardness: | > 2HB |
Coating adhesive: | not lower than first grade Impact: no any crack (50kg/cm, ASTMD-2794:1993) |
Bend stength: | >100 times |
Boiling point: | no any distortion and color change (in the 99 more or less 1 degree water, then cooling 2 hours) |
Corrosive: | surface deep in the 5% muriatic acid and 5% NaCL, interior deep in the 2% muriatic acid and 2% NaCL, after 48 hours, no change |
Characteristics Of Color-Coated Aluminum Sheets/Coils
Smoothness:
There are no composite high temperature indentations on the surface. There is no residual stress on the board surface and no deformation after shearing.
Decorative:
Painted with wood grain and stone grain, it has a realistic physical texture and a vivid natural beauty. The patterns can be made randomly, giving customers a wide range of personal choices, enriching the humanistic connotation of the product, and giving people more beautiful enjoyment.
Weather resistance:
The paint pattern formed by continuous coating and high-temperature baking has high gloss retention, good color stability, and minimal color difference changes. Polyester paint has a 10-year warranty, and fluorocarbon paint has a 20-year or more warranty.
Mechanical:
Use high-quality aluminum materials, plastics and adhesives, and adopt advanced composite technology. The product has the bending and flexural strength required for decorative panels. Under four-season climate conditions, changes in wind pressure, temperature, humidity and other factors will not cause bending, deformation, expansion, etc.
Environmental protection:
Resistant to salt, alkali and acid rain corrosion, will not corrode or produce poisonous bacteria, does not release any toxic gases, will not cause corrosion of keels and fixings, and is flame retardant. According to national regulations, it shall not be lower than B1 level.
Application Of Color-Coated Aluminum Sheets/Coil
Color-coated aluminum coils have a rich range of colors. Whether they are residential buildings, large commercial outlets or large convention and exhibition centers, color-coated aluminum coils can add color to them.
Building | Venetian blinds, rolling shutters, ceiling panels, roofing, façade, ACP Panel. Eveas etc. |
Roller Shutter | Aluminium Composite Panel (ACP), Ceiling, Roofing etc |
Industry | an ideal material for white appliances such as refrigerator due to it’s property of electrical and thermal conductivity, and corrosion resistance |
Transport | truck body, caravan, buses, insulated and refrigerated vehicle |
Signs | Application in Signs requires high colour consistency and flat surface. UAL can fulfill the requirements with excellent performance. |
