5005 Aluminum Sheet and Plate
5005 aluminum plate has the same strength as 3003, good weldability and processability. 5005 aluminum plate is similar to 3003 alloy, with medium strength and good corrosion resistance. The anodized film is brighter than that on 3003 alloy and harmonizes with the color tone of 6063 alloy
Email: export@xienuoenterprise.com
5005 Aluminum Sheet and Plate
5005 aluminum plate has the same strength as 3003, good weldability and processability. 5005 aluminum plate is similar to 3003 alloy, with medium strength and good corrosion resistance.
The anodized film is brighter than that on 3003 alloy and harmonizes with the color tone of 6063 alloy
5005 Aluminum Plate DC / CC Alloy Designation (For Reference)
| Alloy Series | Chinese Standard | American Standard | European Standard |
| 5xxx Series | 5005 | 5005 | ENAW-5005 |
5005 Aluminum Plate DC / CC Chemical Compositing
Chemical Composition conforms to Chinese, American and European standard specification (For Reference)
| Alloy | Si | Fe | Cu | Mn | Mg | Zn | Cr | Others:Each |
| 5005 | 0.30 | 0.70 | 0.20 | 0.20 | 0.5-1.1 | 0.25 | 0.15 | 0.05 |
Product Videos
Mechanical Properties Of 5005 Aluminum Plate
Conditional yield strength σ0.2 (MPa): ≥125
5005 Aluminum Plate DC / CC Available Size Range
| Alloy | 5005 Aluminum Plate |
| Temper | O, H12, H14, H16, H18, H19, H22, H24, H26, H28, H32, H34, H36, H38, H111, H112, T4, T6, T651. |
| Thickness（mm） | 0.2-10.0mm |
| Width（mm） | 500-2800mm |
| Standards | GB, EN, ASTM, AISI, JIS, DIN. |
| Surface Treatment | Anodizing, Color coating, Embossing, Lamination, Polishing etc. |
| Packaging | Standard export wooden box/pallet packaging, suitable for sea transportation |
5005 Aluminum Plate CC / DC Temper (For Reference)
| Temper | Definition |
| O | Annealed |
| H12 | Strain Hardened, 1/4 Hard |
| H14 | Strain Hardened, 1/2 Hard |
| H16 | Strain Hardened, 3/4 Hard |
| H18 | Strain Hardened, Full Hard |
| H22 | Strain Hardened and Partially Annealed, 1/4 Hard |
| H24 | Strain Hardened and Partially Annealed, 1/2 Hard |
| H26 | Strain Hardened and Partially Annealed, 3/4 Hard |
| H28 | Strain Hardened and Partially Annealed, Full Hard |
Characteristics Of 5005 Aluminum Plate
1. High tensile strength, high elongation and good welding performance.
2. It has good forming and processing performance and corrosion resistance.
3. It has good oxidation deep processing performance; compared with 3003 aluminum alloy, the surface of 5005 aluminum alloy is brighter after anodization.
Application Of 5005 Aluminum Plate
1. 5005 aluminum plate is used in automobile panels: vehicle interior materials such as automobile inspection fixtures, automobile fenders, automobile parts, automobile interior materials and other products.
2. Other uses of 5005 aluminum plates: commonly used as conductors, cooking utensils, instrument panels, shells and building decorations, building materials and interior and exterior decoration materials, etc.
