3104 Aluminum Coil and Strip
3104 aluminum coil has appropriate elongation, good corrosion resistance, good processing performance, and can be smelted and processed into alloys of different hardness according to different application requirements.
Email: export@xienuoenterprise.com
3104 Aluminum Coil and Strip
3104 aluminum coil has appropriate elongation, good corrosion resistance, good processing performance, and can be smelted and processed into alloys of different hardness according to different application requirements.
3104 Aluminum Coil DC / CC Alloy designation (For Reference)
Comparison of Alloy Designations for 3004 aluminum sheet coil.
| Alloy Series | Chinese Standard | American Standard | European Standard |
| 3xxx Series | 3104 | 3104 | EN AW-3104 |
3104 Aluminum Coil DC / CC Chemical Compositing
Chemical Composition conforms to Chinese, American and European standard specification (For Reference)
| Alloy | Si | Fe | Cu | Mn | Zn | C | Mg |
| 3104 | 1.0-1.5 | 0.7 | 0.05 | 1.0-1.5 | 0.05 | 0.1 | 0.05 |
3104 Aluminum Coil DC / CC Temper designation (For Reference)
| Temper | Definition |
| O | Annealed |
| H12 | Strain Hardened, 1/4 Hard |
| H14 | Strain Hardened, 1/2 Hard |
| H16 | Strain Hardened, 3/4 Hard |
| H18 | Strain Hardened, Full Hard |
| H22 | Strain Hardened and Partially Annealed, 1/4 Hard |
| H24 | Strain Hardened and Partially Annealed, 1/2 Hard |
| H26 | Strain Hardened and Partially Annealed, 3/4 Hard |
| H28 | Strain Hardened and Partially Annealed, Full Hard |
Mechanical properties of 3104 aluminum coil
3104 aluminum is a deformed aluminum alloy with a tensile strength greater than or equal to 275MPA and a relatively large elongation.
3104 Aluminum Coil DC / CC Available Size Range
| Alloy | 3104 |
| Temper | O, H12, H14, H16, H18, H19, H22, H24, H26, H28, H32, H34, H36, H38, H111, H112, T4, T6, T651. |
| Thickness（mm） | 0.3-6.0mm |
| Width（mm） | 30-1850mm |
| Standards | GB, EN, ASTM, AISI, JIS, DIN. |
| Surface Treatment | Anodizing, Color coating, Embossing, Lamination, Polishing etc. |
| Packaging | Standard export wooden box/pallet packaging, suitable for sea transportation |
Characteristics of 3104 aluminum coil
3104 aluminum coil Because the content of metallic manganese in the aluminum-manganese alloy is stable near its saturation point, under the joint action of other metals, 3104 aluminum alloy has appropriate elongation, good corrosion resistance, and good processing performance.
And it can be smelted and processed into alloys with different hardness according to different application requirements.
Application of 3104 aluminum coil
3104 aluminum coil has good deep drawing and corrosion resistance properties, and is easy to process and form. It is widely used in aluminum shutters, lamp base materials, can lid materials, automobile fuel tanks, aluminum bottle cap materials, pipe insulation, etc.
