3003 Aluminum Circle and Disc
3003 aluminum discs are often used to make lightweight automotive power battery casings, cookers, food storage, cans on transportation equipment, warehouses, metal plate pressure vessels and pipes.
Email: export@xienuoenterprise.com
3003 Aluminum Circle and Disc
3003 Aluminum Circle DC / CC Alloy Designation (For Reference)
3003 aluminum circles blank of XieNuo Aluminum Company is produced according to the standards of chinese GB.
| Alloy Series | Chinese Standard | American Standard | European Standard |
| 3xxx Series | 3003 | 3003 | – |
3003 Aluminum Circle DC / CC Chemical Compositing
Chemical Composition conforms to Chinese, American and European standard specification (For Reference)
| Alloy Series | Chinese Standard | American Standard | European Standard |
| 3xxx Series | 3003 | 3003 | – |
Product Videos
Mechanical Properties of 3003 aluminum Circle
| Tensile strength σb (MPa) | 120-160 |
| Conditional yield strength σ0.2 (MPa) | ≥85 |
3003 Aluminum Circle CC / DC Diameter Tolerance
| Nominal Diameter | Tolerance |
| Diameter tolerance | +/- 1mm |
3003 Aluminum Circle CC / DC Temper (For Reference)
| Temper | Definition |
| O | Annealed |
| H12 | Strain Hardened, 1/4 Hard |
| H14 | Strain Hardened, 1/2 Hard |
| H16 | Strain Hardened, 3/4 Hard |
| H18 | Strain Hardened, Full Hard |
| H22 | Strain Hardened and Partially Annealed, 1/4 Hard |
| H24 | Strain Hardened and Partially Annealed, 1/2 Hard |
| H26 | Strain Hardened and Partially Annealed, 3/4 Hard |
| H28 | Strain Hardened and Partially Annealed, Full Hard |
Characteristics Of 3003 Aluminum Circle
1. Has excellent anti-rust properties.
2. Good molding performance, high corrosion resistance, good weldability and electrical conductivity, and higher strength than 1100.
3. The surface is smooth and has good plasticity and pressure resistance.
4. The power battery shell plate is shock-resistant, not easy to be damaged and leaked, and can meet the strength and stiffness requirements of the power battery shell.
Application Of 3003 Aluminum Circle
3003 aluminum discs are often used to make lightweight automotive power battery casings, cookers, food storage, cans on transportation equipment, warehouses, metal plate pressure vessels and pipes.
