2 Bar Aluminum Checkered Plate
2 Bar aluminum checkered plate is a common anti-slip material. We can see it everywhere in our lives, whether it is the stairs in our homes, subway cars, or the anti-slip floors of large venues.
Email: export@xienuoenterprise.com
2 Bar Aluminum Checkered Plate
2 Bar aluminum checkered plate is a common anti-slip material. We can see it everywhere in our lives, whether it is the stairs in our homes, subway cars, or the anti-slip floors of large venues.
2 Bar Aluminum Checkered Plate Specification and Size
| Alloy | 1050 1060 1070 1100 3003 5052 5754 6061 7075 8011 |
| Temper | O H12 H14 H16 H18 H22 H24 H26 H32 T4 T6 |
| Thickness (base) | 0.2--20.0mm |
| Embossing depth | 0.08~0.25 |
| Width | 100mm-1650mm |
| Length | 500mm-16000mm |
| Pattern | hammer |
| MOQ | 2 ton |
| Payment Terms | T/T L/C |
| Delivery Time | About 20 working days |
2 bar Aluminium Tread Plate Chemical Compositing
Chemical Composition conforms to Chinese, American and European standard specification (For Reference) of aluminium chequer plate sheets.
| Alloy | Si | Fe | Cu | Mn | Mg | Cr | Zn | Ti | Others:Each | Others:Total | Al:Min. |
| 1050 | 0.25 | 0.40 | 0.05 | 0.05 | 0.05 | – | 0.05 | 0.05 | 0.03 | – | 99.5 |
| 1060 | 0.25 | 0.35 | 0.05 | 0.03 | 0.03 | – | 0.05 | 0.03 | 0.03 | – | 99.6 |
| 1100 | 0.95 Si + Fe | 0.05-0.2 | 0.05 | – | – | 0.10 | – | 0.05 | 0.15 | 99.0 | |
| 3003 | 0.60 | 0.70 | 0.05-0.2 | 1.0-1.5 | – | – | 0.25 | 0.15 | 0.05 | 0.15 | remainder |
| 3105 | 0.60 | 0.70 | 0.03 | 0.3-0.8 | 0.2-0.8 | 0.20 | 0.40 | 0.10 | 0.05 | 0.15 | remainder |
| 5052 | 0.25 | 0.40 | 0.10 | 0.10 | 2.2-2.8 | 0.15-0.35 | 0.10 | – | 0.05 | 0.15 | remainder |
| 5754 | 0.40 | 0.40 | 0.10 | 0.50 | 2.6-3.6 | 0.30 | 0.20 | 0.15 | 0.05 | 0.15 | remainder |
Application Of 2 Bar Aluminum Tread Checker Plate
2 Bar aluminium tread plate has many advantages such as beautiful appearance, anti-skid, and strengthening performance. It is widely used in transportation, construction, decoration, equipment surrounding floor, machinery, shipbuilding and other fields.
