1100 Aluminum Sheet and Plate
1100 is industrial pure aluminum with an aluminum content (mass fraction) of 99.00% and cannot be strengthened by heat treatment. It has high corrosion resistance, electrical conductivity and thermal conductivity, low density, good plasticity, and can produce various aluminum materials through pressure processing.
1100 Aluminum Sheet DC / CC Alloy Designation (For Reference)
| Alloy Series | Chinese Standard | American Standard | European Standard |
| 1xxx Series | 1100 | 1100 | ENAW-1100 |
1100 Aluminum Sheet DC / CC Chemical Compositing
Chemical Composition conforms to Chinese, American and European standard specification (For Reference)
| Alloy | SI | Fe | Cu | Mn | Zn | Others:Each | Others:Total | Al:Min. |
| 1100 | 0.95 Si + Fe | 0.05-0.20 | 0.05 | 0.1 | 0.05 | 0.15 | 99.0 | |
Product Videos
Mechanical Properties Of 1100 Aluminum Sheet
Tensile strength σb (MPa): 110 ~ 136.
Elongation δ10 (%): 3 ~ 5.
1100 Aluminum Sheet DC / CC Available Size Range
| Alloy | 1100Aluminum Sheet |
| Temper | O, H12, H14, H16, H18, H19, H22, H24, H26, H28, H32, H34, H36, H38, H111, H112, T4, T6, T651. |
| Thickness（mm） | 0.016-500mm |
| Width（mm） | 100-2650mm |
| Standards | GB, EN, ASTM, AISI, JIS, DIN. |
| Surface Treatment | Anodizing, Color coating, Embossing, Lamination, Polishing etc. |
| Packaging | Standard export wooden box/pallet packaging, suitable for sea transportation |
1100 Aluminum Sheet CC / DC Temper (For Reference)
| Temper | Definition |
| O | Annealed |
| H12 | Strain Hardened, 1/4 Hard |
| H14 | Strain Hardened, 1/2 Hard |
| H16 | Strain Hardened, 3/4 Hard |
| H18 | Strain Hardened, Full Hard |
| H22 | Strain Hardened and Partially Annealed, 1/4 Hard |
| H24 | Strain Hardened and Partially Annealed, 1/2 Hard |
| H26 | Strain Hardened and Partially Annealed, 3/4 Hard |
| H28 | Strain Hardened and Partially Annealed, Full Hard |
Characteristics Of 1100 Aluminum Sheet
1. 1100 aluminum plate is a pure aluminum plate with low density, low strength, soft material and low price.
2. Strong durability: 1100 aluminum plate has high durability and is not easily affected by wind, rain, sun exposure and other factors. This allows it to be used in outdoor environments for a long time without frequent maintenance and replacement.
3. Optional coating treatment: The surface of the 1100 aluminum plate can be coated to increase its weather resistance and decorative properties. Some coatings can also provide better fire protection and anti-slip effects and are suitable for the needs of certain special fields.
Application Of 1100 Aluminum Sheet
1100 is usually used for products that require good forming performance, high corrosion resistance, and do not require high strength, such as food and chemical handling and storage equipment, sheet metal products, hollow hardware processed by drawing and spinning, and welded combination keys , reflectors, nameplates, etc.
