1100 Aluminum Circle and Disc
It has high corrosion resistance, electrical conductivity and thermal conductivity. It has low density and good plasticity. It can produce various aluminum materials through pressure processing. Low strength, but good ductility, formability and weldability.
Email: export@xienuoenterprise.com
1100 Aluminum Circle and Disc
1100 Aluminum Circle DC / CC Alloy Designation (For Reference)
1100 aluminum discs blank of XieNuo Aluminum Company is produced according to the standards of chinese GB.
| Alloy Series | Chinese Standard | American Standard | European Standard |
| 1xxx Series | 1100 | 1100 | – |
1100 Aluminum Circle DC / CC Chemical Compositing
Chemical Composition conforms to Chinese, American and European standard specification (For Reference)
| Alloy | SI | Fe | Cu | Mn | Zn | Others:Each | Others:Total | Al:Min. |
| 1100 | 0.95 Si + Fe | 0.05-0.20 | 0.05 | 0.1 | 0.05 | 0.15 | 99.0 | |
Product Videos
Mechanical Properties Of 1100 Aluminum Circle
| Tensile strength σb (MPa) | ≥95 |
| Conditional yield strength σ0.2 (MPa) | ≥50 |
| Elongation 50mm | ≥9 |
1100 Aluminum Circle CC / DC Diameter Tolerance
| Nominal Diameter | Tolerance |
| Diameter tolerance | +/- 1mm |
1100 Aluminum Circle CC / DC Temper (For Reference)
| Temper | Definition |
| O | Annealed |
| H12 | Strain Hardened, 1/4 Hard |
| H14 | Strain Hardened, 1/2 Hard |
| H16 | Strain Hardened, 3/4 Hard |
| H18 | Strain Hardened, Full Hard |
| H22 | Strain Hardened and Partially Annealed, 1/4 Hard |
| H24 | Strain Hardened and Partially Annealed, 1/2 Hard |
| H26 | Strain Hardened and Partially Annealed, 3/4 Hard |
| H28 | Strain Hardened and Partially Annealed, Full Hard |
Characteristics Of 1100 Aluminum Circle
1. It has high corrosion resistance, electrical conductivity and thermal conductivity. It has low density and good plasticity. It can produce various aluminum materials through pressure processing.
2. Low strength, but good ductility, formability and weldability.
3. Further improve the corrosion resistance after anodization and obtain a beautiful surface at the same time
Application Of 1100 Aluminum Circle
1100 aluminum discs are generally used in food and chemical processing and storage equipment, sheet metal products, hollow hardware processed by wire drawing and spinning, welding combination keys, reflectors, nameplates, etc.
