1070 Aluminum Coil and Strip
1070 Aluminum Coil alloy has the best corrosion resistance, and its strength decreases depending on the purity of the aluminum. It is used in products that do not require high strength, such as chemical instruments, thin plate processing parts, deep drawn or spinning concave vessels, welded parts, heat exchangers, Clock surfaces and disks, nameplates, kitchen utensils, decorations, reflective equipment, reflective plates, chemical industry containers, etc.
Email: export@xienuoenterprise.com
1070 Aluminum Coil and Strip
1070 aluminum coil has high plasticity, corrosion resistance, good electrical and thermal conductivity, and is suitable for gaskets and capacitors made from aluminum foil.
1070 Aluminum Coil DC / CC Chemical Compositing
The composition of 1070 aluminum is relatively simple compared to other aluminum alloys. The main component is aluminum element (Al), and its purity reaches more than 99.7%. The content of other elements, such as iron (Fe) content does not exceed 0.25%, copper (Cu) content does not exceed 0.04%, manganese (Mn) content does not exceed 0.03%, zinc (Zn) content does not exceed 0.04%, The content of silicon (Si) does not exceed 0.2%.
| Alloy | Si | Fe | Cu | Mn | Zn | Ti | V | Al |
| 1070 | 0.2 | 0.25 | 0.04 | 0.03 | 0.04 | 0.03 | 0.05 | 99.7 |
Product Videos
Mechanical properties of 1070 aluminum coil
| Tensile strength σb (MPa) | 55～95 |
| Elongation δ5 (%) | ≥30 |
| The conductivity can reach more than | 35.7 S/m |
| Note | Mechanical properties of pipes at room temperature |
| Sample size | Strip thickness>0.8～1.3 |
1070 Aluminum Coil DC / CC Available Size Range
| Alloy | 1070 |
| Temper | O, H12, H14, H16, H18, H19, H22, H24, H26, H28, H32, H34, H36, H38, H111, H112, T4, T6, T651. |
| Thickness（mm） | 0.2-500 |
| Width（mm） | 100-2650 |
| Standards | GB, EN, ASTM, AISI, JIS, DIN. |
| Surface Treatment | Anodizing, Color coating, Embossing, Lamination, Polishing etc. |
| Packaging | Standard export wooden box/pallet packaging, suitable for sea transportation |
Characteristics of 1070 aluminum coil
1. Low density, good electrical and thermal conductivity, good corrosion resistance, and good plastic processing performance
2. Can be processed into plates, strips, foils and extruded products, etc.
3. Can perform gas welding, argon arc welding and spot welding
4. It cannot be strengthened by heat treatment. The strength can be improved through cold deformation. The only form of heat treatment is annealing.
1070 Aluminum Coil DC / CC Application
1070 Aluminum Coil alloy has the best corrosion resistance, and its strength decreases depending on the purity of the aluminum. It is used in products that do not require high strength, such as chemical instruments, thin plate processing parts, deep drawn or spinning concave vessels, welded parts, heat exchangers, Clock surfaces and disks, nameplates, kitchen utensils, decorations, reflective equipment, reflective plates, chemical industry containers, etc.
